| Part No | 90NX0881-M02840 |
| Sales Model Name | P1503CVA-C516512G0D |
| EAN Code | 4711636346320 |
| UPC Code | 199291346321 |
| WEEE | 1.273 |
| BASE UNIT | VSNX0881-BU21C1 |
| Operating System | Non-preinstalled OS |
| Office | |
| LCD cover-material | Plastic |
| LCD cover-color | Misty Grey |
| Top case-material | Plastic |
| Top case-color | Misty Grey |
| Bottom case-material | Plastic |
| Bottom case-color | Misty Grey |
| Military grade | US MIL-STD 810H military-grade standard |
| Panel Size | 15.6-inch |
| Backlit | LED Backlit |
| OLED | |
| Brightness | 300nits |
| Resolution | FHD (1920 x 1080) 16:9 |
| Glare | Anti-glare display |
| Color gamut | NTSC: 45% |
| View angle(H/V) | 170/170 |
| Response time(Typ/Max) (ms) | 20/25 |
| Refresh rate | 60Hz |
| Contrast (Typ) | 800:1 |
| Touch Panel | Non-touch screen |
| Screen-to-body ratio | 87 % |
| Pantone | |
| IPS-level | Wide view |
| VESA CERTIFIED Display HDR | |
| Processor | Intel® Core™ 5 Processor 210H 2.2 GHz (12MB Cache, up to 4.8 GHz, 8 Cores, 12 Threads) |
| Neural processor | |
| Chipset | N/A |
| Discrete/Share | Share |
| Integrated GPU | Intel® Graphics |
| VRAM | N/A |
| How to upgrade memory | Upgradable
Need to remove bottom/top case |
| Expansion Slot(includes used) | 2x DDR5 SO-DIMM slots
1x M.2 2230 PCIe 4.0x4
1x M.2 2280 PCIe 4.0x4 |
| On board memory | |
| DIMM Memory | 16GB DDR5 SO-DIMM |
| Total System Memory | DDR5 16GB |
| Storage | 512GB M.2 2280 NVMe™ PCIe® 4.0 SSD
SSD Housing for storage expansion |
| Front-facing camera | 720p HD camera
With privacy shutter |
| Wireless | Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card |
| On board Wireless | |
| NumberPad | N/A |
| FingerPrint | FingerPrint |
| Keyboard type | Chiclet Keyboard with Num-key |
| I/O ports | 2x USB 3.2 Gen 1 Type-A
2x USB 3.2 Gen 2 Type-C support display / power delivery
1x HDMI 1.4, up to 3840x2160p/30Hz
1x 3.5mm Combo Audio Jack
1x RJ45 Gigabit Ethernet |
| Audio | Audio by Dirac
Built-in speaker
Built-in array microphone |
| Battery | 50WHrs, 3S1P, 3-cell Li-ion |
| AC Adapter | TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord) |
| Required charging power | Min: 55W
Max: 90W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher. |
| Dimension (WxHxD) | 35.95 x 23.22 x 1.99 ~ 1.99 cm (14.15" x 9.14" x 0.78" ~ 0.78") |
| Weight (with Battery) | 1.66 kg (3.66 lbs) |
| Weight (w/o Battery) | 1.47 kg (3.24 lbs) |
| Security | Fingerprint sensor intergrated with Touchpad
Kensington Nano Security Slot™(6x 2.5mm)
BIOS Booting User Password Protection
BIOS setup user password
HDD User Password Protection and Security
Support Absolute Persistence 2.0 (Computrace)
Trusted Platform Module (TPM) 2.0
N/A |
| Antivirus | |
| MyASUS feature | System diagnosis
Battery health charging
Fan Profile
Splendid
Tru2Life
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS |
| MyExpert Features | N/A |
| Built-in Apps | AI ExpertMeet (AI features need devices with 12GB RAM or more)
MyASUS |
| Disclaimer for Built-in Apps | |
| Included in the Box | |
| Reparability Index (for France) | 9.3 |
| Reparability Index (for Belgium) | 9.2 |
| Ecolabels & Compliances | EPEAT Gold with Climate+
Energy star 8.0
FSC Recycled
REACH
RoHS
TCO Certified |
| Base Warranty | 2Y Pick up/ return |
| Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty | ACX11-004802NX//1Y Extension
ACX11-00482DNX//3Y Extension
ACX11-004840NX//1Y Extension
3Y OnSite Service(Next Business Day)*upgrade
*If you would like to know the details, please contact your sales teams. |
| Battery warranty | Commercial NB P series Battery warranty follow system warranty. |
| Sustainable Material_Top cover(A part) | 30% PCR recycled plastic(cover or inner frame) |
| Sustainable Material_Panel frame (B part) | |
| Sustainable Material_Keyboard frame (C part) | 30% PCR recycled plastic(cover or inner frame) |
| Sustainable Material_Bottom cover (D part) | 30% PCR recycled plastic(cover or inner frame) |
| Sustainable Material_Battery | 30% PCR recycled plastic |
| Sustainable Material_Keyboard | |
| Sustainable Material_Speaker | |
| Sustainable Material_Total PCR recycled plastic | 26.1% |
