| Standartlar ve Protokoller | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x |
|---|
| Arabirim | • 24× 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
• 4× Gigabit SFP Slots
|
|---|
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
• 1000BASE-X: MMF, SMF
|
|---|
| Fan Sayısı | 2 |
|---|
| PoE+ Portları (RJ45) | • Standard: 802.3at/af compliant
• PoE+ Ports: 24 Ports
• Power Supply: 250 W
|
|---|
| Boyutlar ( W X D X H ) | 17.3 × 8.7 × 1.73 in (440 × 220 × 44 mm) |
|---|
| Montaj | Rack Mountable |
|---|
| Maks. Güç Tüketimi | • 32.1 W (110 V/ 60 Hz with no PD connected)
• 308.6 W (110 V/ 60 Hz with 250 W PD connected) |
|---|
| Max Heat Dissipation | 109.53 BTU/h (with no PD connected)
• 1052.94 BTU/h (with 250 W PD connected) |
|---|
